Eaton Pow-R-Line Switchboard MDSC4N | 4000 Amp Main Breaker | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

Eaton Pow-R-Line Switchboard; 4000 amp main breaker- cat # MDSC4N3HEA, 480Y/277 volt, 3 phase, 4 wire, LSIG functions, ground fault, NEMA 1 indoor rated. With (1) Pull Section & (2) sections of breaker distribution panels. Reconditioned & guaranteed with a one-year warranty.

4 Sections: From Right to Left

Pull Section

Main Breaker Panel

• Eaton IQ 250/260 Meter
• Clipper Power System Surge Protection Device

  • 300 kA
• 4000 Amp Magnum DS Main Breaker
  • MDSC4N
  • Cat # MDSC4N3HEA 405GA MNN2E PKNAX
  • 3 Pole
  • Accessories
    • Aux Switches- 2A/ 2B
  • Digitrip 520 Trip Unit
    • Cat # 5LSIG
      • LSIG Functions
      • Ground Fault

Breaker Distribution 1 Panel

• 1600 Amp Breaker
  • RD 65k
  • Cat # RD316T32W
  • 3 Pole
  • Digitrip RMS 310 Trip Unit
    • Cat # RES1600LSI
      • LSI Functions
  • Digitrip RMS 310 Rating Plug
    • Cat # 16RES16T

Breaker Distribution 2 Panel

• 1600 Amp Breaker
  • RD 65k
  • Cat # RD316T32W
  • 3 Pole
  • Digitrip RMS 310 Trip Unit
    • Cat # RES1600LSI
    • LSI functions
  • Digitrip RMS 310 Rating Plug
    • Cat # 16RES16T
• 1200 Amp Breaker
  • HND 65k
  • Cat # HND312T32W
  • 3 Pole
  • Digitrip RMS 310 Trip Unit
    • Short Delay
  • Digitrip RMS 310 Rating Plug
    • 1200 Amp
      • Cat # 12NES1200T

Dimensions:

• Pull Panel
  • 45" Width
  • 48" Depth
  • 90" Height

• Main Panel
  • 45" Width
  • 48" Depth
  • 90" Height

• Distribution 1 Panel
  • 36" Width
  • 48" Depth
  • 90" Height

• Distribution 2 Panel
  • 45" Width
  • 48" Depth
  • 90" Height

M-749                        LOC: Across from Pillar 148
