GE AV-Line Switchboard 2000 Amp 480 Volt 3Ph 4W NEMA 1 R&G

Product description:

General Electric AV-Line switchboard; 2000 amp Power Break II Main Breaker, 480 volt, 3 phase, 4 wire, ground fault, NEMA 1. Reconditioned & guaranteed with a one year warranty.

2 Sections: From Right to Left

Main Breaker Panel:

  • PQM II Power Quality Meter
  • Transient Voltage Surge Suppressor
  • 2000 Amp Main Breaker
    • Cat# SSD20B220
    • 480 Volt AC
    • 3 Pole
    • Rating Plug: TR20B
      • 2000 Amp
      • TR20B2000
    • Shunt Trip
      • SPST120
    • MicroVersaTrip Plus Trip Unit
      • Cat# B220LSIG
      • LSIG Functions
      • Ground Fault
  • 1600 Amp Power Break II Breaker
    • Cat# SSD16B216
    • 480 Volt AC
    • 3 Pole
    • Rating Plug: TR16B
      • 1600 Amp
      • TR16B1600
    • Shunt Trip
      • SPST120
    • MicroVersaTrip Plus Trip Unit
      • Cat# B216LSIG
      • LSIG Functions
      • Ground Fault
  • 800 Amp Power Break II Breaker
    • Cat# SSD08B204
    • 480 Volt AC
    • 3 Pole
    • Rating Plug: TR4B
      • 200 Amp
      • TR4B200
    • Shunt Trip
      • Cat# SPST120
    • MicroVersaTrip Plus Trip Unit
      • Cat# B204LSIG
        • LSIG Functions
        • Ground Fault

Distribution Breaker Panel

  • (2) 1600 Amp Power Break II Breaker
    • Cat# SSD16B216
    • 480 Volt AC
    • 3 Pole
    • Rating Plug: TR16B
      • 1600 Amp
      • TR16B1600
    • Shunt Trip
      • SPST120
    • MicroVersaTrip Plus Trip Unit
      • Cat# B216LSIG
      • LSIG Functions
      • Ground Fault
  • (2) 800 Amp Power Break II Breaker
    • Cat# SSD08B208
    • 480 Volt AC
    • 3 Pole
    • Rating Plug: TR8B
      • 800 Amp
      • TR8B800
    • Shunt Trip
      • Cat# SPST120
    • MicroVersaTrip Plus Trip Unit
      • Cat# B204LSIG
        • LSIG Functions
        • Ground Fault

Dimensions:

  • Main Panel
    • 53" Width
    • 60" Depth
    • 96" Height
  • Distribution Panel
    • 45" Width
    • 60" Depth
    • 96" Height

M567              LOC: Pillar 144

Specs:

  • Manufacturer : General Electric
  • Style : Breaker
  • Main Type : Circuit Breaker
  • Amperage : 2000
  • Voltage : 480
  • Phase : 3
  • Wire : 4
  • Ground Fault : Yes
  • Indoor/Outdoor : Indoor
  • Condition : Refurbished
SKU: M567
