General Electric Spectra Series Switchboard TP3030TTR | 3000 Amp Main Breaker | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

General Electric Spectra Series Switchboard; 3000 amp main breaker- cat # TP3030TTR, 480Y/277 volt, 3 phase, 4 wire, ground fault, surge protection device, NEMA 1 indoor rated. With (1) Pull section panel & (1) spectra distribution breaker panel. Reconditioned & guaranteed with a one-year warranty.

4 Sections: From Left to Right

Main Breaker Panel

• 3000 Amp Power Break Main Breaker
  • Cat # TP3030TTR
  • MicroVersaTrip Plus Trip Unit
    • Cat # C330LIG
      • LIG Functions
      • Ground Fault
  • 3000 Amp Rating Plug
    • Cat # TR30B3000

Surge Protection Panel

• Electronic Surge Protection Device

Spectra Breaker Distribution Panel

• (2) 1200 Amp Spectra RMS Breaker
  • Cat # SKLB36BA1200
  • 1000 Amp Rating Plug
    • Cat # SRPK1200B1000
• (2) 800 Amp Spectra RMS Breaker
  • Cat # SKLA36AT0800
  • 800 Amp Rating Plug
    • Cat # SRPK800A800
• (1) 400 Amp Spectra RMS Breaker
  • Cat # SGLA36AT0400
  • 150 Amp Rating Plug
    • Cat # SRPG400A150

Pull Section Panel

Dimensions:

• Main Panel
  • 45" Width
  • 48" Depth
  • 90" Height

• Surge Protection Panel
  • 35" Width
  • 35" Depth
  • 90" Height

• Spectra Dist Panel
  • 45" Width
  • 35" Depth
  • 90" Height
• Pull Panel
  • 30" Width
  • 35" Depth
  • 90" Height
