General Electric Spectra Switchboard TP3030TTR | 3000 Amp Main Breaker | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

General Electric Spectra Switchboard; 3000 amp main breaker- cat # TP3030TTR, 480Y/277 volt, 3 phase, 4 wire, LIG functions, NEMA 1 indoor. With (1) pull section & (1) section of spectra breaker distribution. Reconditioned & guaranteed with a one-year warranty.

3 Sections: From Right to Left

Pull Panel

Main Panel

• (1) 3000 Amp Power Break
  • Cat # TP3030TTR
  • MicroVersaTrip Plus Trip Unit
    • Cat # C330LIG
      • LIG Functions
      • Ground Fault
  • 3000 Amp Rating Plug
    • Cat # TR30B3000

Distribution Spectra Panel

• (1) 800 Amp
  • Cat # SKHA36AT0800
  • Rating Plug- # SRPK800A800
• (2) 600 Amp
  • Cat # SGLA36AT0600
  • Rating Plug- # SRPG600A600
• (1) 400 Amp
  • Cat # SGLA36AT0400
  • Rating Plug- # SRPG400A400
• (3) 250 Amp
  • Cat # SFHA36AT0250
  • Rating Plug- # SRPF250A175
• (1) 250 Amp
  • Cat # SFLA36AT0250
  • Rating Plug- # SRPF250A175
• (1) 150 Amp
  • Cat # SELA36AT0150
  • Rating Plug- Cat # SRPE150A150
• (1) 150 Amp
  • Cat # SEDA36AT0150
  • Rating Plug- # SRPE150A110
• (1) 100 Amp
  • Cat # SELA36AT0100
  • Rating Plug- # SRPE100A90
• (2) 100 Amp
  • Cat # SELA36AT0100
  • Rating Plug- # SRPE100A70
• (2) 60 Amp
  • Cat # SELA36AT0060
  • Rating Plug- # SRPE60A60
• (2) 60 Amp
  • Cat # SELA36AT0060
  • Rating Plug- Cat # SRPE60A50

Dimensions:

• Pull Panel
  • 35" Width
  • 35" Depth
  • 90" Height

• Main Panel
  • 40" Width
  • 35" Depth
  • 90" Height

• Distribution Panel
  • 40" Width
  • 35" Depth
  • 90" Height

M-724              LOC: Pillar 116 (SPR-C3)
