Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O

Home > Circuit Breakers > Molded & Insulated Case Circuit Breakers > Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O

Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Picture of Square D MasterPact NW16L1 Circuit Breaker 1600 Amp 600 Volt AC M/O D/O
Be the first to review this product

Product description:

Square D MasterPact NW16L1 Circuit Breaker; cat # WA8EER64A3SXBXWXCA, 1600 amp frame, 600 volt, 3 pole, 1600 amp rated, manually operated (M/O), draw-out (D/O). With micrologic 6.0P trip unit- LSIG functions, ground fault, shunt trip- 24-30 volt AC/DC. Used tested with a report.

MC-CB # 2266 -- LOC:  B5I2                          MC-CB # 2278 -- LOC: B5J1

MC-CB # 2279 -- LOC: B5J1

Specs:

  • Manufacturer : Square D
  • Family : Masterpact
  • Frame : NW
  • Amperage : 1600
  • Voltage : 600V
  • Poles : 3
  • Shunt Trip : Yes
  • Ground Fault : Yes
  • Functions : LSIG - Long-Time, Short-Time, Instantaneous, Ground
  • Operation : Manual
  • Fixed Mount or Draw Out : Draw Out
  • Condition : Used
Brand: Square D
Availability: In stock
SKU: MCCB2266
$3,300.00
