Square D Power-Style Switchboard 3000 Amp Main Lug Only 120/208 Volt 3 Ph 4W NEMA 1 R&G

Product description:

Square D Power-Style Switchboard; 3000 Amp main lug only, 120/208 volt AC, 3 phase, 4 wire, NEMA 1 indoor rated. With 1600 amp distribution switch & 3 distribution sections. Reconditioned & guaranteed with a one-year warranty.

4 Sections: From Left to Right

Fusible Distribution 1 Section

  • (5) QMB-3240 fusible switches
    • 400 Amp
    • 240 Volt AC
    • 3 Pole
    • Series 4

Main Lug Only Fusible Section

  • 3000 Main Lug Only
  • 120/208 Volt
  • 3 Phase, 4 Wire
  • Bolt-Loc Bolted Pressure Contact Switch
    • 1600 Amp
    • 240 Volt AC
    • 60Hz
    • MFG# 44004-122-50

Fusible Distribution Section 2

  • (6) QMB-324 fusible switches
    • 200 Amp
    • 3 Pole
    • 240 Volt AC
    • Series D2
  • (2) QMB-323-TD
    • 100 Amp
    • 3 Pole
    • 240 Volt AC
    • Series D2

Distribution Fusible Section 3

  • (3) QMB-324 fusible switches
    • 200 Amp
    • 3 Pole
    • 240 Volt AC
    • Series D2
  • (6) QMB-323-TD
    • 100 Amp
    • 3 Pole
    • 240 Volt AC
    • Series D2
  • (4) QMB-322-TD
    • 60 Amp
    • 3 Pole
    • 240 Volt AC
    • Series D2
  • (4) QMB-321-T
    • 30 Amp
    • 3 Pole
    • 240 Volt AC
    • Series D2

Dimensions: All 4 Sections have the same dims

  • 36" Width
  • 36" Depth
  • 90" Height

M-524          LOC: Pillar 148

Specs:

  • Manufacturer : Square D
  • Style : Fusible
  • Amperage : 3000
  • Voltage : 208Y/120
  • Ground Fault : No
  • Indoor/Outdoor : Indoor
  • Phase : 3
  • Wire : 4
  • Condition : Refurbished
  • Main Type : Main Lug Only
Brand: Square D
SKU: M524
