Square D Power Style Switchboard BP03620Z | 1600 Amp Main Fusible | 480/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

Square D Power Style Switchboard; 1600 amp fusible main bolt-loc switch- cat # BP03620Z, 480/277 volt, NEMA 1 indoor. With (1) I-line breaker distribution panel. Reconditioned & guaranteed with a one-year warranty.

2 Sections: From Right to Left

Main Fusible Section

  • Bolt-Loc bolted pressure contact switch
  • 1600 Amp
  • Cat # BP03620Z
  • 480/277 Volt
  • 3 Phase
  • 4 Wire
  • Meters
  • Type GC Monitor
  • NEMA 1 indoor rated

I-line Breaker Distribution Section

  • (2) 800 Amp Sensor (Frame) Electronic Trip Circuit Breaker
  • Cat# ME36800LSG
  • Series 5
  • 480 Volt
  • Ground Fault
  • Micrologic
    • Rating Plug
    • Cat# RP075
  • (2) 400 Amp Sensor (Frame) Solid State Trip Circuit Breaker
  •  Cat# ME36400LSG
  • 480 Volt
  • Series 5
  • Ground Fault
  • Micrologic
    • Rating Plug
    • Cat# RP100

Dimensions: 2 Sections

  • Fusible Main
    • 36" Width
    • 37" Depth
    • 90" Height
  • I-Line Distribution
    •  36" Width
    •  37' Depth
    • 90" Height

(M-506         LOC: Transformer Rows 14 & 15)

Specs:

  • Manufacturer : Square D
  • Main Type : Fusible
  • Style : Breaker
  • Amperage : 1600
  • Voltage : 480Y/277
  • Phase : 3
  • Wire : 4
  • Ground Fault : Yes
  • Indoor/Outdoor : Indoor
  • Condition : Refurbished
Brand: Square D
Availability: In stock
SKU: M506
