Square D Power Style Switchboard BPO3630EI | 3000 Amp Fusible Main | 208Y/120V 3- Phase 4-Wire | NEMA 1 R&G

Product description:

Square D Power Style Switchboard; 3000 amp fusible main switch- cat # BPO3630EI, 208Y/120 volt, 3 phase, 4 wire, NEMA 1 indoor rated. With (2) sections of QMJ/QMBW fusible distribution panels & (1) Pull/Empty panel. Reconditioned & guaranteed with a one-year warranty.

4 Sections: From Left to Right

Fusible Main Panel

• PowerLogic Circuit Monitor
• 3000 Amp Fusible Main Switch
  • Cat # BPO3630EI

Fusible Distribution Panel 1

• (1) QMJ366
  • 600 Amp
• (1) QMJ365
  • 400 Amp
• (4) QMJ364T
  • 200 Amp

Fusible Distribution Panel 2

• (1) QMJ365
  • 400 Amp
• (4) QMJ364T
  • 200 Amp
• (1) QMJ363T
  • 100 Amp

Pull/ Empty Panel

Dimensions:

• Main Panel
  • 42" Width
  • 36" Depth
  • 90" Height

• Distribution 1 Panel
  • 48" Width
  • 36" Depth
  • 90" Height

• Distribution 2 Panel
  • 48" Width
  • 36" Depth
  • 90" Height

• Pull/ Empty Panel
  • 48" Width
  • 36" Depth
  • 90" Height

M-750          LOC: Pillar 157
