Square D Power-Zone 4 Switchboard NW50H3 | 5000 Amp Main-Tie-Main | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

Square D Power Zone 4 Switchboard; 5000 amp main-tie-main- cat # NW50H3, 480Y/277 volt AC, three phase, four wire, ground fault, NEMA 1 indoor. With MasterPact breaker distribution. Reconditioned & guaranteed with a one-year warranty.

3 Sections: From Left to Right

Main (1) Panel

• (2) 3200 Amp MasterPact Breaker
  • NW32H3
  • Cat # WA6JGR43A3SFFFXHXA
  • MicroLogic 5.0 A
    • LSI Functions

Tie Panel

• PowerLogic PM800 Monitor
• No Breakers

Main (2) Panel

• (1) 5000 Amp MasterPact Breaker
  • NW50H3
  • Cat # YA6LLR64A3SFFFXHXA
  • MicroLogic 6.0 A
    • LSIG Functions
• (1) 2000 Amp MasterPact Breaker
  • NW20H3
  • Cat # WA6FFR44A9SFFFXHXX
  • Micrologic 6.0 A
    • LSIG Functions
• (1) 1600 Amp MasterPact Breaker
  • NW16H3
  • Cat # WA6EER44A9SFFFXHXX
  • Micrologic 6.0 A
    • LSIG Functions

Dimensions:

• Main (1) Panel
  • 80" Width
  • 73" Depth
  • 94" Height

• Tie Panel
  • 36" Width
  • 73" Depth
  • 94" Height

• Main (2) Panel
  • 94" Width
  • 73" Depth
  • 94" Height

M-228                LOC: Pillar 134 (F-9)
