Square D QED Power Style Switchboard NW40BH2 | 4000 Amp Main Breaker | 480Y/277V 3-Phase 4-Wire | NEMA 3R Surplus

Product description:

Square D QED Power Style Switchboard; 4000 amp main breaker- cat # WA5KKZ64A3SXFXXXXA, 480Y/277 volt, 3 phase, 4 wire, LSIG functions, ground fault, RELT, NEMA 3R outdoor rated. With (2) sections of breaker distribution panels. New Surplus

3 Sections from Left to Right

Main Breaker Panel

• Main RELT Switch
• SurgeLogic Surge Protective Device
• 4000 Amp MasterPact Main Breaker
  • NW40BH2
  • Cat # WA5KKZ64A3SXFXXXXA
  • Micrologic 6.0 P Trip Unit
    • LSIG Functions
    • Ground Fault

Breaker Distribution 1 Panel

• (18) 125 Amp PowerPact Breakers
  • Cat # BJA36125

Breaker Distribution 2 Panel

• (18) 125 Amp PowerPact Breakers
  • Cat # BJA36125

Dimensions:

• Main Panel
  • 42" Width
  • 63" Depth
  • 92" Height

• Distribution 1 Panel
  • 42" Width
  • 63" Depth
  • 92" Height

• Distribution 2 Panel
  • 42" Width
  • 63" Depth
  • 92" Height

M-701                        LOC: Pillar 157 (Main & Dist 1) Pillar 148 (Dist 2)
