Square D QED Power Style Switchboard BPO3630EI | 3000 Amp Fusible Main | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

Square D QED Power Style Switchboard; 3000 amp fusible main switch- cat # BPO3630EI, 480Y/277 volt, 3 phase, 4 wire, ground fault indicator, NEMA 1 indoor rated. With (3) sections of QMJ/QMBW fusible distribution panels. Reconditioned & guaranteed with a one-year warranty.

4 Secions: From Right to Left

Fusible Main Panel

• Power Logic Circuit Monitor
• Ground Fault Indicator
• 3000 Amp Fusible Main Switch
  • Cat # BPO3630EI

Fusible Distribution 1 Panel

• (1) QMJ365
  • 400 Amp
• (5) QMJ364T
  • 200 Amp
• (2) QMJ363T
  • 100 Amp
• (2) QMJ361T
  • 30 Amp

Fusible Distribution 2 Panel

• (2) QMB368W
  • 1200 Amp
• (1) QMJ364T
  • 200 Amp

Fusible Distribution 3 Panel

• (3) QMJ364T
  • 200 Amp
• (3) QMJ363T
  • 100 Amp
• (1) QMJ362
  • 60 Amp
• (1) QMJ361T
  • 30 Amp

Dimensions:

• Main Panel
  • 42" Width
  • 36" Depth
  • 90" Height

• Distribution 1 Panel
  • 48" Width
  • 36" Depth
  • 90" Height

• Distribution 2 Panel
  • 48" Width
  • 36" Depth
  • 90" Height

• Distribution 3 Panel
  • 48" Width
  • 36" Depth
  • 90" Height

M-751                   LOC: Pillar 157
