Square D

Square D PBTB-306G I-Line series plug-in tap boxes; 400/600 amp, 600 volt, three phase, three-wire, aluminum/copper. Reconditioned and guaranteed with a one year warranty.

Square D PBTB-506G I-Line series plug-in tap boxes; 400/600 amp, 480Y/277 volt, three phase, four-wire, copper/aluminum. Reconditioned and guaranteed with a one year warranty.

Square D PTB-302G I-Line series plug-in tap boxes; 225 amp, 600 volt, three phase, three-wire, copper/aluminum. Reconditioned and guaranteed with a one year warranty.

Square D PTB-316G I-Line series plug-in tap boxes; 800-2000 amp, 600 volt, three phase, three-wire, copper/aluminum. Reconditioned and guaranteed with a one year warranty.

Square D PTB-502G I-Line series plug-in tap boxes; 225 amp, 480Y/277 volt, three phase, four-wire, copper/aluminum. Reconditioned and guaranteed with a one year warranty.

Square D PTB-516G I-Line series plug-in, tap boxes; 800-3000 amp, 600 volt, three phase, four-wire, copper/aluminum. Reconditioned and guaranteed with a one year warranty.

Square D Iso-Flex Medium Voltage Motor Controller Model 3: type CG42, 1st Starter (MVS# 32): *SOLD *, 2nd Starter (MVS# 33): Set Voltage: 4160 Volt, 3 Phase, 120 Volt Control, Set Horsepower: 300HP, Set Amperage: 200 Full Load Amps. Contactor: Class 8110, type V3540A, Form JPDX32, 5000V (5KV), 360A. 3rd Starter (MVS# 34): Set Voltage: 4160 Volt, 3 Phase, 120 Volt Control, Set Horsepower: 900HP, Set Amperage: 200 Full Load Amps. Auto Transformer: Rated 1000HP, 4160 Volt, 133 FLA (50%/65%/80% Taps). (A Contactor)- Class 8110, Type V2540C, Form JPDX32, 360 Amps, 5000V (5kv). (B Contactor)- Class 8110, Type V2540C, Form LRDX11, 2 Pole, 360 Amps, 5000V (5kv). (C Contactor)- Class 8110, Type V3540A, Form LRDX01, 2 Pole, 360 Amps, 5000V (5kv), Fused with 9R Fuses. 1200 Amp Horizontal Bus Structure: 92"H x 108"W x 33"D (Plus 3" for lifting bar). Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type K-Factor Transformer: Cat # 150T3HFISNLP, 150 KVA, primary voltage: 480 volt, secondary voltage: 208Y/120 volt, 3 phase, NEMA 1 indoor rated. Reconditioned & guaranteed with a one-year warranty. *K-Factor Not to Exceed 13

Square D Low Voltage Dry Type Transformer: Cat # 75T3H, 75 KVA, primary voltage: 480 volt, secondary voltage: 208Y/120 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: Cat # 112T3HISNLP, 112.5 KVA, primary voltage: 480 volt, secondary voltage: 208Y/120 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: Cat # 145T105HDIT, 145 KVA, primary voltage: 460 volt, secondary voltage: 460Y/265 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: Cat # 166T029597, 166 KVA, primary voltage: 480Y/277 volt, secondary voltage: 434Y/251 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: 220 KVA, primary voltage: 460 volt, secondary voltage: 460Y/266 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: Cat # 225T6H, 225 KVA, primary voltage: 480 volt, secondary voltage: 240 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: 25 KVA, primary voltage: 240 x 480 volt, secondary voltage: 120Y/240 volt, 1 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: 30 KVA, primary voltage: 208Y/120 volt, secondary voltage: 115 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: 30 KVA, primary voltage: 480 volt, secondary voltage: 208Y/120 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: Cat # 30T3H, 30 KVA, primary voltage: 480 volt, secondary voltage: 208/120 volt, 3 phase, NEMA 3R outdoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: Cat # 37S3H, 37.5 KVA, primary voltage: 240x480 volt, secondary voltage: 120/240 volt, 1 phase, NEMA 1 Indoor. Reconditioned & guaranteed with a one-year warranty.

Square D Low Voltage Dry Type Transformer: Cat # 45T12H, 45 KVA, primary voltage: 240 volt, secondary voltage: 208Y/120 volt, 3 phase, NEMA 1 indoor rated. Reconditioned & guaranteed with a one-year warranty.
